Tekin T-440 Crawler/Monster Truck, Element Proof Servo

Hit the trails hard with the Tekin T-440 Crawler Servo. Rocks, Mud, Dirt or Snow. The Element Proof Design means you can tackle any terrain. Full Metal Gear set, All Aluminum Housing, Digital Position Encoding and loads of Torque, this servo keeps you out of a bind. Fine-tune your setup with an extensive set of adjustments via Tekin’s HotWire PC Interface.

 SPECS

Torque: 8.4  - 7.4  - 6.0V

             502 - 460 - 421 oz/in

             36.2 - 33.1 - 30.3 kg/cm
Dynamic Torque: 8.4  - 7.4  - 6.0V
                              578 - 550 - 499 oz/in

                              41.6 - 39.6 - 35.6 kg/cm
Speed: 8.4  -  7.4  - 6.0V

            0.11 - 0.13 - 0.15sec/60°

Input Voltage: 4.8V-8.4V
Gear Set: Full Metal

Dimensions: 1.57 x 0.79 x 1.57in / 40 x 20 x 40mm

Mounting Height (Base to Mount Tabs): 1.10in / 28.4mm

Weight: 2.57oz / 73g

FEATURES

Digital Magnetic Position Encoder (DPE)

Specifically Designed for 1/12 and 1/10 Scale Applications

Included Aluminum Vector Servo Arm

Full Aluminum Servo Housing

Element Proof Design*

Precision Cut Full Metal Gears

ABEC5 Ball Bearings

High Voltage Capable

High Torque Coreless Motor

25T Output Spline
